Description
Virdi UBio-X Pro 2 — Second-Generation AI Face Recognition & Fingerprint Terminal in Pakistan
The Virdi UBio-X Pro 2 is the second-generation successor to the UBio-X Pro — a significantly upgraded multi-modal biometric access control and time attendance terminal that introduces three major new capabilities over its predecessor: web-based face pre-enrollment, mobile self-registration, and NFC mobile access via BLE 4.2. Combined with AI facial recognition from up to 3 meters, HID card support, AES-256 encryption with Azure Key Vault, and a massive 500,000 user capacity, the UBio-X Pro 2 delivers enterprise-grade security with a level of deployment convenience not available in any previous Virdi Pro series terminal.
IOT Systems is the sole and authorized Virdi UBio distributor in Pakistan. Every UBio-X Pro 2 we supply is 100% genuine, factory-certified, covered by full manufacturer warranty from Virdi Korea, and supported by official firmware updates and manufacturer-backed technical assistance.
Important — No IP Rating: Indoor Installation Only
The Virdi UBio-X Pro 2 has no dust or water resistance rating and is designed for indoor installation only. For outdoor installations, see the Virdi AC-2200 (IP65) or AC-2000 (IP65 + IK09 vandal-proof).
UBio-X Pro 2 vs UBio-X Pro — What’s New in Generation 2
| Feature | UBio-X Pro | UBio-X Pro 2 |
|---|---|---|
| Web Face Pre-Enrollment | ✗ | ✓ NEW |
| Mobile Self-Registration | ✗ | ✓ NEW |
| NFC / BLE 4.2 Mobile Access | ✗ | ✓ NEW |
| AES-256 + Azure Key Vault | ✗ | ✓ NEW |
| Face Templates (1:N) | 150,000 (10/user) | 30,000 (5/user) |
| Face Templates (1:1) | 200,000 | 200,000 |
| HID Card Support | ✓ | ✓ |
| Max Users (Card) | 500,000 | 500,000 |
| Operating Temperature | -20°C to +60°C | -20°C to +60°C |
| IP Rating | None (Indoor) | None (Indoor) |
The UBio-X Pro 2’s lower 1:N face template count (30,000 with 5 templates per user) compared to the Pro (150,000 with 10 templates per user) reflects a deliberate design choice — the Pro 2 prioritizes recognition accuracy per user with fewer but higher-quality templates, while adding the convenience features (mobile enrollment, NFC access, web pre-enrollment) that enterprise users need. Contact IOT Systems for guidance on which model is right for your requirements.
New Features in the UBio-X Pro 2
Web-Based Face Pre-Enrollment: The UBio-X Pro 2 provides a simple web interface that allows HR administrators to upload and pre-enroll employee face images remotely — without requiring employees to physically present themselves at each terminal. For large organizations deploying hundreds or thousands of users, web pre-enrollment can save days of enrollment time compared to terminal-by-terminal face capture.
Mobile Self-Registration: New employees can self-register their face credentials in under 30 seconds using their smartphone — entering name, email, setting a password, and uploading a profile photo via camera or gallery. Two-factor authentication is supported for secure self-registration. Eliminates the need for HR to manually enroll each employee at a terminal.
NFC / BLE 4.2 Mobile Access: Employees use their smartphone (iOS 10+ or Android 6+) as an access credential via NFC tap or Bluetooth Low Energy. No physical card required. Read range under 10cm. All credentials are protected by AES-256 encryption with Azure Key Vault support.
AES-256 + Azure Key Vault Encryption: All biometric data is stored as encrypted minutiae points — no original biometric images are ever stored on the device. AES-256 encryption with Azure Key Vault ensures full compliance with GDPR and international biometric data protection regulations.
Authentication Modes
Face Recognition: AI dual-camera recognition from up to 3 meters. 30,000 face templates (1:N, 5 templates per user), 200,000 (1:1, 10 templates per user). Operates in 0 to 30,000 Lux. Anti-spoofing liveness detection using visible light and IR rejects photographs, video playback, and 3D masks. FRR 0.1% / FAR 0.0001%.
Fingerprint: Large 15.5 × 19mm platen at 500 DPI. 1,000,000 fingerprint templates (1:1) and 200,000 (1:N). Patented fake fingerprint detection. Up to 2 templates per finger, 10 fingers per user.
RFID Cards: EM 125kHz, HID Prox, HID iCLASS, and 13.56MHz smart cards — all four in one built-in reader.
NFC / BLE Mobile Access: Smartphone credentials via NFC tap or Bluetooth Low Energy. iOS 10+ and Android 6+. Under 10cm read range. AES-256 encrypted.
PIN Code: 5-inch color touch LCD with soft keypad. Standalone or combined multi-factor authentication.
UBio Alpeta — Cloud Management Platform
The UBio-X Pro 2 connects to UBio Alpeta — Virdi’s official web-based access control and time attendance platform.
Real-Time Attendance — Monitor every access and attendance event live across all sites simultaneously.
Automated Payroll Reports — Export to Excel, SAP, Microsoft Dynamics 365, and Power BI automatically.
Access Level Control — Define which users access which doors at which times per individual or group.
Multi-Site Management — Manage terminals across Karachi, Lahore, Islamabad, and all branches from one dashboard.
Remote User Enrollment — Add or update credentials remotely without visiting each terminal.
Free SDK & API — Official Virdi UBio SDK and API provided free by IOT Systems with every deployment.
Who Uses the Virdi UBio-X Pro 2 in Pakistan?
Large Corporate Offices — Mobile self-registration and web pre-enrollment dramatically simplify large-scale deployment for big organizations
Banks & Government Buildings — HID card support plus NFC mobile access and AES-256 encryption for maximum indoor security
Manufacturing Plants — Massive fingerprint template capacity for large workforces with mobile enrollment convenience
Universities & Campuses — Mobile self-registration lets new students enroll their own credentials without HR intervention
Hospitals & Healthcare — Thermal camera integration for health screening alongside facial recognition access control
Organizations Upgrading from UBio-X Pro — All the Pro’s capabilities plus mobile enrollment, NFC access, and AES-256 encryption
Multi-Site Organizations — UBio Alpeta cloud platform with NFC mobile credentials enables truly card-free multi-site management
Why Buy the Virdi UBio-X Pro 2 from IOT Systems?
Sole Authorized Distributor — The only genuine source of Virdi UBio products in Pakistan. No gray-market risk. No warranty void.
Full Manufacturer Warranty — Official Virdi Korea manufacturer warranty on every terminal.
Free SDK & API — Official UBio Alpeta SDK and API included at no extra cost with every deployment.
Certified Installation — Certified engineers install, configure, and commission across Karachi, Lahore, Islamabad, and all major cities.
Latest Firmware — Every terminal shipped with the latest official Virdi firmware.
After-Sales Support — Dedicated support for firmware updates, troubleshooting, system expansion, and training.
Download the official datasheet: [Virdi UBio-X Pro 2 Datasheet PDF]
Frequently Asked Questions — Virdi UBio-X Pro 2
What is new in the UBio-X Pro 2 compared to the UBio-X Pro?
The UBio-X Pro 2 adds three major new capabilities: web-based face pre-enrollment (HR can upload faces remotely without visiting each terminal), mobile self-registration (employees register themselves in under 30 seconds via smartphone), and NFC/BLE 4.2 mobile access (smartphone replaces physical card). It also adds AES-256 encryption with Azure Key Vault. The Pro 2 has a lower 1:N face template count (30,000 vs 150,000) but this reflects 5 higher-quality templates per user versus the Pro’s 10 templates per user.
Why does the UBio-X Pro 2 have fewer face templates (1:N) than the UBio-X Pro?
The UBio-X Pro stores 150,000 face templates using 10 templates per user — supporting 15,000 users in 1:N mode. The UBio-X Pro 2 stores 30,000 face templates using 5 templates per user — supporting 6,000 users in 1:N mode. The Pro 2 uses fewer but higher-quality templates per user, prioritizing recognition accuracy. If very high 1:N capacity is the priority, the UBio-X Pro remains the right choice. Contact IOT Systems for guidance.
Does the UBio-X Pro 2 support HID cards?
Yes. The UBio-X Pro 2 supports EM 125kHz, HID Prox, HID iCLASS, and 13.56MHz smart cards — all in one built-in reader without any adapter.
Can the UBio-X Pro 2 be installed outdoors?
No. The UBio-X Pro 2 has no IP dust or water resistance rating and is designed for indoor installation only. For outdoor installations choose the Virdi AC-2200 (IP65) or AC-2000 (IP65 + IK09 vandal-proof).
Does the UBio-X Pro 2 work offline without internet?
Yes. All templates, access rules, and event logs are stored locally. It operates completely without internet. When internet is available, data syncs automatically to UBio Alpeta.
Does IOT Systems install the UBio-X Pro 2 outside Karachi?
Yes. IOT Systems provides installation, UBio Alpeta configuration, and after-sales support across Pakistan — Karachi, Lahore, Islamabad, Rawalpindi, Faisalabad, Multan, Hyderabad, Peshawar, and Quetta.
