Protege DIN Rail Cellular Modem in Pakistan

The Protege DIN Rail Cellular Modem is a secure and reliable wireless communication device designed to provide seamless connectivity for Protege access control controllers in Pakistan. It enables remote communication without the need for traditional wired network infrastructure, making it ideal for remote and hard-to-reach installations.

This modem is widely used in security systems where network availability is limited, expensive, or impractical to install. It ensures continuous connectivity for monitoring, reporting, and system management.

Wireless Communication for Remote Security Systems

The Protege DIN Rail Cellular Modem enables wireless IP communication for access control and alarm systems, allowing secure data transmission from remote sites to central monitoring stations.

It is compatible with both Protege GX and Protege WX controllers, making it a flexible solution for different security system architectures.

  • Wireless IP alarm transmission
  • Remote site connectivity support
  • Compatible with Protege GX and WX systems
  • Ideal for infrastructure-free installations

Advanced Cellular Network Technology

The modem supports modern cellular technologies including 4G LTE-M and NB-IoT, ensuring stable and efficient communication even in low-power or remote environments.

It also includes fallback support for 2G GSM networks, ensuring uninterrupted connectivity in areas with limited coverage.

  • 4G LTE-M support
  • NB-IoT low-power connectivity
  • Category M1 cellular capability
  • 2G GSM fallback support

Secure & Encrypted Data Transmission

The Protege DIN Rail Cellular Modem ensures secure communication through encrypted data transmission, especially when used with ArmorIP reporting services. This enhances protection against unauthorized access and data interception.

Its secure communication protocols make it suitable for high-security environments such as banks, industrial sites, and government installations.

Cost-Effective Remote Monitoring Solution

By eliminating the need for physical networking infrastructure, the modem provides a cost-effective solution for remote monitoring and alarm reporting systems.

  • Reduces installation and wiring costs
  • Ideal for remote and rural locations
  • Fast deployment for security systems
  • Reliable cloud-based reporting support

Applications of Protege DIN Rail Cellular Modem

The Protege DIN Rail Cellular Modem is widely used in professional security and automation systems where remote communication is required.

  • Remote industrial security sites
  • Banking and financial institutions
  • Government monitoring systems
  • Commercial building security systems
  • Oil, gas, and utility infrastructure
  • Access control and alarm reporting systems

Reliable Security Connectivity Solution in Pakistan

The Protege DIN Rail Cellular Modem provides a powerful and flexible communication solution for modern security systems in Pakistan. Its wireless connectivity, encrypted transmission, and multi-network support make it ideal for critical remote installations.

It is widely deployed in Karachi, Lahore, Islamabad, Faisalabad, and other major cities for enterprise-grade access control and security monitoring applications.

Ordering Information
PRT-4G-USB Protege DIN Rail Cellular Modem
Power Supply
Operating Voltage 12V DC
Operating Current 300mA (Max)
Communication
USB USB-C
SIM Card Socket Micro-SIM
Cellular Technology 4G, Dual Mode LTE-M / NB-IoT
LTE Cat-M1 Uplink up to 1 Mbps, Downlink up to 588 Kbps
LTE Cat-NB2 Uplink up to 160 Kbps, Downlink up to 120 Kbps
Operating Frequencies (LTE) B1, B2, B3, B4, B5, B8, B12, B13, B18, B19, B20, B25, B26, B27, B28, B66, B71, B85
Antenna Connection
Antenna Connector SMA
Antenna Impedance 50 Ohm
Antenna Gain / VSWR 5dBi, ≤2
Antenna Frequency 4G wide band 600–2700 MHz
Polarization & Radiation Vertical, Omnidirectional
Length 320 ± 3 mm (12.6 ± 0.12")
Base Diameter 30 ± 2 mm (1.18 ± 0.08")
Mounting Magnetic Base
Dimensions
Dimensions (L x W x H) 39 x 90 x 60mm (1.53 x 3.54 x 2.36")
Net Weight 70g (2.5oz)
Gross Weight 200g (7.1oz)
Operating Conditions
Operating Temperature -10° to 55°C (14° to 131°F)
Storage Temperature -10° to 85°C (14° to 185°F)
Humidity 0%-93% non-condensing, indoor use only (relative humidity)
